my new pin stooge Empty my new pin stooge

Post  roddie Mon Apr 28, 2014 2:32 pm

Easy build; 6" x 6" x 1/2" plywood base with a 1/4" step-block, 3/32" m.w. pin with 7/64" brass-tube guide, x2 landing-gear straps, compression spring and soldered 3/32" wheel-collar along with some small assorted steel washers and a couple of 1-1/8" screw-eyes. The wheel collar helps to compress and hold the spring slightly while soldering it to the pin. Two aluminum gutter spikes (7"L.) on an angle, through two holes in the rear of the base, secure it to the ground.


next comes a handle for the trip-line, that also stores the line... and will dispense up to 70 ft.

my new pin stooge 4-28-110
my new pin stooge 4-28-111
my new pin stooge 4-28-112


Last edited by roddie on Mon Apr 28, 2014 2:43 pm; edited 1 time in total
roddie
roddie
Top Poster
Top Poster

Posts : 8449
Join date : 2013-07-17
Age : 64
Location : N. Smithfield, Rhode Island

http://www.stilburnin.com

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  ian1954 Mon Apr 28, 2014 2:36 pm

Mmmmmm! That may have given me an idea!
ian1954
ian1954
Diamond Member
Diamond Member

Posts : 2688
Join date : 2011-11-16
Age : 69
Location : England

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  roddie Mon Apr 28, 2014 2:49 pm

ian1954 wrote:Mmmmmm! That may have given me an idea!

Ian and Roddie's think-tank..  Thumbs Up Did I strike a nerve with the handle idea perhaps?
roddie
roddie
Top Poster
Top Poster

Posts : 8449
Join date : 2013-07-17
Age : 64
Location : N. Smithfield, Rhode Island

http://www.stilburnin.com

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  ian1954 Mon Apr 28, 2014 4:23 pm

roddie wrote:
ian1954 wrote:Mmmmmm! That may have given me an idea!

Ian and Roddie's think-tank..  Thumbs Up Did I strike a nerve with the handle idea perhaps?

I must admit, handles are a sore point with me. Especially 1/2A handles  Devil

No, as usual, I looked at your ingenuity and thought of something better and it won't need a stringy pully thing with a "handle"!

For me to know and mull over, for you to wonder!   Smoking

This emoticon looks a bit like me with my outdoor specs and a cigarette  Smoking
ian1954
ian1954
Diamond Member
Diamond Member

Posts : 2688
Join date : 2011-11-16
Age : 69
Location : England

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  roddie Mon Apr 28, 2014 5:23 pm

ian1954 wrote:

This emoticon looks a bit like me with my outdoor specs and a cigarette  Smoking

yes... a recent photo of you looking for a certain color "Corsair" comes to mind... amazing resemblance  Laughing

my new pin stooge Ian_sp10
roddie
roddie
Top Poster
Top Poster

Posts : 8449
Join date : 2013-07-17
Age : 64
Location : N. Smithfield, Rhode Island

http://www.stilburnin.com

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  JPvelo Mon Apr 28, 2014 6:21 pm

This is what I came up with for a stooge on larger models:
JPvelo
JPvelo
Diamond Member
Diamond Member

Posts : 1972
Join date : 2011-12-02
Age : 56
Location : Colorado

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  getback Mon Apr 28, 2014 7:12 pm

Just what I was thinking Sunday as my plane was moving to the outside too fast for me as I was setting up to try and fly  lol! I ll show u later but Thanks Roddie I was thinking of you and the pic s I had seen before! Smile Crazy Eyes I thinks that does resemble you Ian1954....  Jim that sound like a 22LR getting ready to go again  lol! I like it!!  Getback  my new pin stooge Wp_20208   my back porch babys 5 of those ... Sparrow's I think
getback
getback
Top Poster
Top Poster

2022 Supporter

2023 Supporter

Posts : 10269
Join date : 2013-01-18
Age : 66
Location : julian , NC

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  pkrankow Mon Apr 28, 2014 7:23 pm

http://www.lowes.com/pd_409640-355-BTHT47226_0__

http://www.lowes.com/pd_349291-258-BNT14P6BK_0__?productId=3462452&Ntt=braided+nylon&pl=1¤tURL=%3FNtt%3Dbraided%2Bnylon&facetInfo=

This is what I am using.

Phil
pkrankow
pkrankow
Top Poster
Top Poster

Posts : 3025
Join date : 2012-10-02
Location : Ohio

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  getback Mon Apr 28, 2014 8:45 pm

cool I have one of those , Never thought of it thow , Thanks Phil ...Getback St.Pats Beers
getback
getback
Top Poster
Top Poster

2022 Supporter

2023 Supporter

Posts : 10269
Join date : 2013-01-18
Age : 66
Location : julian , NC

Back to top Go down

my new pin stooge Empty Re: my new pin stooge

Post  roddie Tue Apr 29, 2014 7:44 am

pkrankow wrote:http://www.lowes.com/pd_409640-355-BTHT47226_0__

http://www.lowes.com/pd_349291-258-BNT14P6BK_0__?productId=3462452&Ntt=braided+nylon&pl=1¤tURL=%3FNtt%3Dbraided%2Bnylon&facetInfo=

This is what I am using.

Phil

Great idea Phil. Funny thing.. but the FL. yellow Mason-line that I'm using; I had passed-over several times, because it was $5.00/spool. It recently went on sale for $2.99!! The chalk-line "reel" is something I never thought of.

I used to wrap my trip-line around my old stooge for storage, and had a small nail tied to the end which I slipped under the wrap to hold it.

I had thought about making different length trip-lines.. 25', 35', 42', etc. with line-connectors on each, to attach to the loop on the release-pin, but I really like the closed chalk-line reel idea, because the crank-handle locks at any line-length you want.

A tail-skid with a "loop" for a stooge-pin is something I've always built-in to my R.O.G. airplanes. I've even drilled a hole through a tail-wheel for a pin. A quick pin-link can be made from a large safety-pin and line connector, by attaching to the tail-gear strut on the inner side of the wheel... or you can fashion one from a piece of small music-wire 1-2" long, with loops on each end; one for the stooge-pin and the other for a line-connector to the model.

Flying alone isn't as much fun as having a buddy or two along.. but if you have to; having a reliable stooge is key.
